Toshiba 20AF41C - Comb Filter

WAVEFORMS
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
NOTE:
31 1V 50µs/div
32 2V 5ms/div
33 2V 5ms/div
34 0.5V 20µs/div
COMB FILTER
35 1V 20µs/div
36 1V 5ms/div
38 50V 20µs/div
37 50V 20µs/div
39 50V 20µs/div
CRT
