Introduction / Getting started
TV front view
7
Left side view
Point the
brightness sensor
(- page 18).
1
2
3
4
5
6
USB
1 1 (power on/standby)—Presstoturnthe
TVon/standby(- page10).
2 pBb (programme position)—Whenno
menuisonscreen,thesebuttonsselectthe
programmeposition.(-page12).
U u(MENU up/down)—Whenamenuis
on-screen,thesebuttonsfunctionasup/
downmenunavigationbuttons(exceptfor
theinputsourceselection)(-page11).
3 2–+(volume)—
Whennomenuison-
screen,thesebuttonsadjustthevolumelevel.
I i(MENU left/right)—Whenamenuis
on-screen,thesebuttonsfunctionasleft/right
menunavigationbuttonsoradjustsettings
(-page11).
4 MENU—Presstoaccessthemenusystem
(-page11).
RETURN—Whenamenuison-screen,
thisbuttonwilltakeyoubacktotheprevious
menu(-page12).
5 o (input source selection)—Whenno
menuisonscreen,thisbuttonselectsthe
inputsource(-page14).
OK—Whenamenuison-screen,this
buttonwillmakeaselectionortakeyouto
thenextavailablemenulayer(-page11).
TV back panel connections
RGB/PC
VIDEO
AUDIO R L / MONO
AUDIO R L / MONO
Y
P R /C R P B /C B
1 2 3 4
PC/
HDMI1
(
AUDIO
)
1
2
AUDIO
(
FIXED
)
COMPONENT VIDEO INPUT
USB
ACIN
Cable holder *
RGB/PC
AUDIO R L / MONO Y
P R /C R P B /C B
PC/
HDMI
(
AUDIO
)
AUDIO
COMPONENT / VIDEO INPUT
(
FIXED
)
VIDEO
Power cord *
ACIN
13
12
11
8
10
9
Cable holder *
Power cord * (only for 32PB1 models)
* Make sure to insert the plugs firmly, when
plugging the AC power cord into the TV set end
and wall outlet end.
* Make sure to hold the plug, when unplugging
the AC power cord.
* Never use other cord except for supplied AC
power cord, and never use the supplied power
cord for any other purpose.
* The exact power cord will vary according to the
country.
Cable holder *
* You can use the cableholder to hold the aerial
cable, video and audio cables etc.
Never grasp the holder when moving the TV.
6 USB (input terminal)—InsertyourUSB
storagedeviceheretoviewphotos(JPEG)
(-page27).
7 1 (power LED)—Powerindicator
(-page10).
8 o HDMI (input terminal)—High-Denition
MultimediaInterfaceinputreceivesdigital
audioanduncompresseddigitalvideofrom
anHDMIdeviceoruncompresseddigital
videofromaDVIdevice(-pages24,25).
