8
Getting started
Installing the P-Clip
NOTES
• Falling down of the product may cause personal injury or product failure.
• Fixed measures are recommended. If the method above can not fix the product, please consult the manufacturers.
• P-Clip is optional, your device may not have P-Clip, please refer to the actual accessories.
Select a suitable screw hole based on the actual situation
Screw: M6 × 12
Screw: ST4 × 25C
P-Clip
P-Clip
A
B
Please fix the
A
part of the P-Clip with the M6 × 12 screw attached to the screw hole on the back of the TV set(marked in the illustration below).
Select a suitable screw hole based on the actual situation, fix the
B
part of the the P-Clip on the wall or other places with the ST4 × 25C screw.
screw hole
To Next Page
