3. Clean with dry lint free cloth mirrors 1, 2, 3, 4 and 5 as well as the expo-lamp reflector A.
4. Clean with isopropyl alcohol the sliders B and C of the carriage 1 and 2. Note – be careful not to
bend carriage 3, because it is mounted only to the rear side of the copier. Bending will result in
copy image skew. See figure 6.
