User’s Manual EN-4
CANVIO BASICS
Installing the drive
Some information about bus-powered operation and the supplied USB
cable:
■ Your drive is bus-powered. Therefore, there is no need to connect an
external power supply as all needed current will be supplied by the
connected USB port(s).
■ Passive USB hubs or USB connectors like keyboards, mice or similar
products cannot be used or connected to the drive.
■ Make sure that the connectors will be inserted correctly.
■ Never use pressure for connecting the cables. Check the polarity before
connecting!
Connecting the drive to your
computer
1. With your computer powered on and fully booted up, plug the USB 3.0
Standard-A connector into a USB port of your host system, or an active
USB HUB.
1. USB 3.0 Micro-B connector 3. USB 3.0 Standard-A connector
2. Power/Data indicator light 4. USB 3.0 host
backward compatible to USB 2.0
You may need USB 3.0 Express Card Host Controller for your computer if
the computer doesn’t have USB 3.0 port. You also can connect the device
to USB 2.0 port of your computer, However the transfer rate will be
downgraded to that of USB 2.0.
