Toshiba DVR80KF Service Manual

1-6-4 E9TK0DC
Note: When removing FFC(B37A) of Capstan Motor from BOARD AV, be sure to replace the new FFC(B37A).
(Don’t solder FFC which removed once again)
[18] BOARD AV
[16] BOARD
DTV MODULE
Unit
[15] Deck
Assembly
[17] BOARD
REAR JACK
FE Head
Cylinder
Assembly
ACE Head
Assembly
[18] BOARD AV
SW507
LD-SW
From
FE Head
BOTTOM VIEW
Lead connections of Deck Assembly and BOARD AV
Desolder
FFC of
Capstan
Motor
Printing side
Desolder
Desolder
Desolder
Desolder
From
Cylinder
Assembly
From
ACE Head
Assembly
Lead with
blue stripe
Lead with
white stripe
(S-22)
(S-23)
LD-SW
Pin
Pin
Hole
Hole
Shaft
Cam Gear
[18] BOARD AV
[15] Deck Assembly
Fig. D7
