Toshiba DVR80KF Service Manual

1-6-1 E9TK0DC
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps to gain
access to item(s) to be serviced. When reassembling,
follow the steps in reverse order. Bend, route, and
dress the cables as they were originally.
2. Disassembly Method
NOTE: BOARD MEANS PRINTED CIRCUIT BOARD.
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
[1] Cover Top D1 9(S-1) ---
[2]
Front
Assembly
D2
*5(L-1), *3(L-2), (S-2),
2(S-3), *CN6001,
USB Holder, USB
Plate Earth
1
[3]
BOARD
USB
D2 ---------- ---
[4]
Front
Bracket
D2
3(S-4), (S-5), Front
Support
---
[1] Cover Top
[2] Front
Assembly
[4] Front Bracket
[20] Front
Bracket R
[21] Bracket R
[17] BOARD
REAR JACK
[5] DVD Mechanism
& DVD MAIN
BOARD Assembly
[9] BOARD
POWER SUPPLY
[10] Power Holder
[12] BOARD
FUNCTION
[6] Fan Holder
[7] Motor DC Fan
[8] Panel Rear
[15] Deck
Assembly
[19] Deck Pedestal
[14] VCR
Chassis Unit
[11] BOARD
SWITCH
[13] BOARD
POWER SWITCH
[3] BOARD USB
[18] BOARD AV
[16] BOARD DTV
MODULE Unit
[5]
DVD
Mechanism
& DVD
MAIN
BOARD
Assembly
D3
(S-6), 2(S-7), 2(S-8),
2(S-9), *CN101,
*CN502-D, *CN701,
*CN901, *CN981,
Dust Cover, Hook,
Mecha Plate Earth
2
[6] Fan Holder D4 2(S-10), *CN1002-P ---
[7]
Motor DC
Fan
D4 2(S-11) ---
[8] Panel Rear D4
2(S-12), 5(S-13),
Rear Holder
---
[9]
BOARD
POWER
SUPPLY
D5
(S-14), 3(S-15),
(S-16), *CL1001,
*CN3605, FFC Guide
---
[10]
Power
Holder
D5 ---------- ---
[11]
BOARD
SWITCH
D5 (S-17), Desolder ---
[12]
BOARD
FUNCTION
D5 2(S-18), *CN1504 ---
[13]
BOARD
POWER
SWITCH
D6 (S-19), Desolder ---
[14]
VCR
Chassis
Unit
D6 5(S-20), 4(S-21) ---
[15]
Deck
Assembly
D7 (S-22), (S-23)
3
4
[16]
BOARD
DTV
MODULE
Unit
D7 Desolder ---
[17]
BOARD
REAR
JACK
D7 Desolder ---
[18] BOARD AV D7 ---------- ---
[19]
Deck
Pedestal
D8 7(S-24) ---
[20]
Front
Bracket R
D8
(S-25), 2(S-26), DV
Cable, DV Plate Earth
---
[21] Bracket R D8 2(S-27) ---
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
