1-14-25
WF1
PIN 56 OF
IC301
WF6
PIN 30 OF
IC1509
PIN 17 OF
CN1502
WF7
PIN 5 OF
CN1502
WF8
WF9
PIN 9 OF
CN1502
WF5
PIN 7 OF
CN1502
WF4
PIN 3 OF
CN1502
PIN 28 OF
CN1503
WF10
BE3TK3F01011A
BOARD AV Bottom View
NOTE: BOARD MEANS PRINTED CIRCUIT BOARD.
