ERROR CODE and TROUBLESHOOTING
8 - 102
[EF12] Saddle Stitch Finisher stapling error (rear)
[EF13] Saddle stitch unit paper holding home position detection error
Check item Measures
Finisher • Is there any paper remaining on the paper transport path
in the Finisher or the equipment, or on the finishing tray?.
• Is the jam released by taking off the front staple cartridge
from the Finisher and removing the staple sheet slid from
the staple case?
Front saddle stapler drive unit • Unit check
• Connector check
• Harness check
Saddle controller board • Connector check (CN3)
• Board check
Replace parts Remarks
Front saddle stapler drive unit
Saddle controller board
Classification Error item
Finisher jam (Saddle section)
Check item Measures
Finisher • Is there any paper remaining on the paper transport path
in the Finisher or the equipment, or on the finishing tray?.
• Is the jam released by taking off the rear staple cartridge
from the Finisher and removing the staple sheet slid from
the staple case?
Rear saddle stapler drive unit • Unit check
• Connector check
• Harness check
Saddle controller board • Connector check (CN3)
• Board check
Replace parts Remarks
Rear saddle stapler drive unit
Saddle controller board
Classification Error item
Finisher jam (Saddle section)
Check item Measures
Finisher • Is there any mechanical problem when the paper holding
cam is rotated?
Paper holding home position sensor
(S38)
• Sensor check
• Connector check
• Harness check
