ERROR CODE and TROUBLESHOOTING
8 - 10
E910 Paper transport jam
(Relay transport
section)
Jam at the bridge unit transport sensor 1:
The paper does not reach the bridge unit
transport sensor 1 after it has passed the
exit sensor.
P. 8-84
E920 Stop jam at the bridge unit transport sensor
1: The trailing edge of the paper does not
pass the bridge unit transport sensor 1 after
its leading edge has reached the sensor.
P. 8-84
E930 Jam at the bridge unit transport sensor 2:
The trailing edge of the paper does not
reach the bridge unit transport sensor 2
after its leading edge has reached the
bridge unit transport sensor 1.
P. 8-85
E940 Stop jam at the bridge unit transport sensor
2: The trailing edge of the paper does not
pass the bridge unit transport sensor 2 after
its leading edge has reached the bridge unit
transport sensor 2.
P. 8-85
E970 Paper transport jam
(Exit section)
Jam not reaching the lower paper exit
sensor: Paper transported from the bridge
unit does not reach the lower paper exit
sensor.
P. 8-41
E980 Stop jam at the lower paper exit sensor:
Paper transported from the bridge unit does
not pass the lower paper exit sensor.
P. 8-42
E9F0 Finisher jam
(Punch unit)
Punching jam: Punching is not performed
properly.
[MJ-1103/1104 (when MJ-6102 is installed)]
P. 8-96
EA10 Finisher jam
(Finisher section)
Transport delay jam (paper not inserted) P. 8-86
EA20 Paper transport jam in Finisher (entrance
sensor)
P. 8-86
EA21 Paper size error jam: Paper does not reach
the sensor because the paper is shorter
than spec. [MJ-1103/1104]
P. 8-87
EA22 Paper transport jam (Finisher paper
punching edge detection sensor): [MJ-
1103/1104]
P. 8-87
EA23 Paper transport jam (exit sensor): [MJ-
1103/1104]
P. 8-88
EA24 Paper transport jam (between entrance and
exit sensors): [MJ-1103/1104]
P. 8-88
EA25 Paper transport jam (after paper stack exit):
[MJ-1103/1104]
P. 8-89
EA26 Paper transport jam (stop command
request): [MJ-1103/1104]
P. 8-89
EA27 Paper transport jam (paper not inserted):
[MJ-1103/1104]
P. 8-89
EA28 Paper transport jam (assisting arm
operation delay): [MJ-1103/1104]
P. 8-90
EA29 Paper transport jam (stack transport delay):
[MJ-1103/1104]
P. 8-90
Error code Classification Contents Troubleshooting
