Toshiba E-studio5540c Service Manual

e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 42
[E980] Stop jam at the lower paper exit sensor
Drive unit, Rollers • Gear check
• Roller check
LGC board • Connector check (CN309)
• Board check
Replace parts Remarks
Lower paper exit sensor
Bridge unit transport exit motor
PFC board
DRV board
LGC board
Exit roller
Classification Error item
Paper transport jam (Relay transport
section)
Paper transported from the bridge unit does not pass the
lower paper exit sensor.
Check item Measures
Lower paper exit sensor • Sensor check
(Perform the input check: 03-[COPY]ON/[5]/[G],
03-[ALL]OFF/[4]/[C])
• Connector check
• Harness check
Exit motor • Motor check
(Perform the output check: 03-140)
• Connector check
• Harness check
PFC board • Connector check (CN500, CN515,CN516)
• Board check
DRV board • Connector check (CN537, CN539, CN540)
• Board check
Drive unit, Rollers • Gear check
• Roller check
LGC board • Connector check (CN309)
• Board check
Replace parts Remarks
Lower paper exit sensor
exit motor
PFC board
DRV board
LGC board
Exit roller
Check item Measures
