EN-13
COUNTERTOP INSTALLATION
Remove all packing material and accessories.
Examine the oven for any damage such as dents or broken door. Do not install if
oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet
surface. Do not remove the light brown Mica cover that is attached to the oven
cavity to protect the magnetron.
INSTALLATION
1. Select a level surface that provide enough open space for the intake and/or
outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is required between the oven and any
adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12 inches (30cm) above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV a s possible.
reception.
3.0 inches(7.5cm)
12 inches(30cm)
OPEN
3.0 inches(7.5cm )
SETTING UP YOUR OVEN
Operation of microwave oven may cause interference to your radio or TV
To Next Page
