Before removing a USB device from the USB port of your computer,
click the Safely Remove Hardware and Eject Media icon on the
Windows taskbar, and then select the USB device that you want to
remove.
Keep foreign metal objects, such as screws, staples, and paper clips, out of
the USB port. Foreign metal objects can create a short circuit, which can
cause damage and fire, possibly resulting in serious injury.
Optical disc drive The computer might be configured with a DVD
Super Multi drive.
2.6GB and 5.2GB DVD-RAM media cannot be read from or written to.
Right side
The following figure shows the right side of the computer.
Figure 3-3 The right side of the computer
1. Memory media slot 5. HDMI out port
2. Headphone/Microphone combo jack 6. Cooling vents
3. Universal Serial Bus (USB 3.0) port 7. Security lock slot
4. Universal Serial Bus (USB 2.0 or 3.0)
port
Memory media slot This slot lets you insert an SD™/SDHC™/
SDXC™ memory card, miniSD™/microSD™
Card and MultiMediaCard™. Refer to the
Memory media section for more information.
Keep foreign metal objects, such as screws, staples, and paper clips, out of
the Memory media slot. Foreign metal objects can create a short circuit,
which can cause damage and fire, possibly resulting in serious injury.
Headphone/
Microphone combo
jack
A 3.5 mm mini headphone/microphone combo
jack enables connection of a monaural
microphone or a stereo headphone.
User's Manual 3-3
