ELECTRICAL REPLACEMENT PARTS LIST

Location No. TSB P/N Reference No. Description

RESISTORS

! R401 72795515 R4X5T6472F R,METAL 4.7K OHM 1/6W

! R403 72794594 R4X5T6183F R,METAL 18K OHM 1/6W

! R405 72795516 R4X5T6153F R,METAL 15K OHM 1/6W

! R406 72795508 R3X18A151J R,METAL OXIDE 150 OHM 2W

! R412 72781738 R63881330J R,FUSE 33 OHM 1W

! R417 72796443 R3X28A221J R,METAL OXIDE 220 OHM 2W

! R423 72794624 R3X18AR68J R,METAL OXIDE 0.68 OHM 2W

! R429 72794597 R002T22R2J RC 2.2 OHM 1/2W

! R430 72797994 R5X34F5R6J R,CEMENT 5.6 OHM 10W

! R434 72797785 R002T21R5J RC 1.5 OHM 1/2W

! R435 72795518 R655822R2J R,FUSE 2.2 OHM 1/2W

! R436 72796461 R3X181101J R,METAL OXIDE 100 OHM 1W

! R440 72795519 R65581010J R,FUSE 1 OHM 1W

R441 75002952 R00202104J RC 100K OHM 1/2W

! R445 72798015 R655811R8J R,FUSE 1.8 OHM 1W

! R454 72796031 R3K181102J R,METAL OXIDE 1K OHM 1W

! R803 72794659 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R805 72794659 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R807 72794659 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R3010 72797880 R3X18A330J R,METAL OXIDE 33 OHM 2W

! R3014 72797927 R3X28B3R3J R,METAL OXIDE 3.3 OHM 3W

R3023 72797776 R00204750J RC 75 OHM 1/4W

! R3800 72796095 R4X5T6332F R,METAL 3.3K OHM 1/6W

! R3803 72795500 R002T2155J RC 1.5M OHM 1/2W

! R3806 72794631 R0G3K2275K RC 2.7M OHM 1/2W

! R3812 72797851 R3X181331J R,METAL OXIDE 330 OHM 1W

! R3817 72797976 R5X2CE010J R,CEMENT 1 OHM 7W

! R3821 72797865 R3X181R22J R,METAL OXIDE 0.22 OHM 1W

! R3828 72794633 R63881R22J R,FUSE 0.22 OHM 1W

CAPACITORS

C130 72797465 E52H02100M CE 10 UF 16V

C357 72797426 E0ELF4102M CE 1000 UF 35V

! C403 72794396 E02LU8220M CE 22 UF 100V

! C408 72783562 P4N8FK472H CMPP 0.0047UF 1.5KV

! C409 72794380 E02LU4101M CE 100 UF 35V

C412 72795564 P4J7F3434J CMPP 0.43 UF 250V PMS

! C417 72797681 P3N1F5333J CPP 0.033 UF 630V

! C418 72797719 P4N8FK133H CMPP 0.013 UF 1.5KV

! C429 72795097 E5EZU4101M CE 100 UF 35V

! C430 72794381 E5EZF3222M CE 2200 UF 25V

! C434 72795831 E5EZF4102M CE 1000 UF 35V

C435 72797509 E62DFD100M CE 10 UF 250V

! C446 72794394 E5EZFD220M CE 22 UF 250V

! C449 72794399 C0PLRR713K CC 0.001 UF 2KV R

C802 72794440 C0JBB07H3K CC 0.0022UF 2KV B

! C3801 72795566 P2122B224M CMP 0.22 UF 275V ECQUL

! C3810 72795629 C0JTB0513K CC 0.001 UF 500V B

! C3811 72795073 C0PLRR7G3K CC 0.0018 UF 2KV R

! C3812 72795629 C0JTB0513K CC 0.001 UF 500V B

! C3815 72797461 E52DHC681M CE 5 680 UF 200V

! C3816 72795579 CD39E0MQ3M CC 0.0047UF 250V

! C3818 72797478 E5EZF2332M CE 3300 UF 16V

! C3822 72797483 E5EZT2102M CE 1000 UF 16V

! C3823 72794410 E5EZF3102M CE 1000 UF 25V

! C3824 72794399 C0PLRR713K CC 0.001 UF 2KV R

! C3826 72796328 E61SFC221M CE 220 UF 200V

! C3827 72794381 E5EZF3222M CE 2200 UF 25V

DIODES

D101 72794491 D1VT001330 DIODE,SILICON 1SS133T-77

D102 72794489 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

D105 72794491 D1VT001330 DIODE,SILICON 1SS133T-77

D106 72794491 D1VT001330 DIODE,SILICON 1SS133T-77

D301 72794491 D1VT001330 DIODE,SILICON 1SS133T-77

D401 72794491 D1VT001330 DIODE,SILICON 1SS133T-77

! D402 72794472 D2WTAU02A0 DIODE,SILICON AU02A-EIC

D403 72794488 D2WT011E10 DIODE,SILICON 11E1-EIC

D404 72794488 D2WT011E10 DIODE,SILICON 11E1-EIC

! D405 72797302 D2BFRS4FS0 DIODE,SILICON RS-4FS

! D406 72796383 D2BFRU4AM0 DIODE,SILICON RU-4AM

! D407 72794472 D2WTAU02A0 DIODE,SILICON AU02A-EIC

! D408 72794489 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

D410 72794488 D2WT011E10 DIODE,SILICON 11E1-EIC

D411 72794489 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

! D412 72794472 D2WTAU02A0 DIODE,SILICON AU02A-EIC

D413 72794471 D97U03001B DIODE,ZENER MTZJ30B T-77

J3-1

Brand	Toshiba
Model	MD24F52
Category	TV DVD Combo
Language	English

Toshiba MD24F52 User Manual
