– 35 –
Function CODE No. (DN Code) table (includes all functions needed to perform applied control on site)
DN Item Description At shipment
01
Filter display delay timer 0000: None
0002: 2500H
0004: 10000H
0001: 150H
0003: 5000H
According to type
02
Dirty state of filter 0000: Standard
0001: High degree of dirt (Half of standard time)
0000: Standard
1E
Temp difference of
[AUTO] mode selection
COOL → HEAT,
HEAT → COOL
0000: 0 deg
(For setup temperature, reversal of COOL / HEAT by } (Data value) / 2)
0010: 10 degto 0003: 3 deg
(Ts ±1.5)
06
Heating temp shift 0000: No shift
0002: +2 ûC
0001: +1 ûC
0010: +10 ûC
(Up to +6 recommended)
to
0002: +2 ûC
(Floor type 0000: 0 ûC)
2E
HA terminal (CN61)
select
0000: Usual
0002: Fire alarm input
0001: Leaving-ON prevention control 0000: Usual
(HA terminal)
2A
Selection of option / error
input (CN70)
0000: Filter input
0002: None
0001: Alarm input (Air washer, etc.) 0002: None
28
Automatic restart of
power failure
0000: None 0001: Restart 0000: None
14
Group address 0000: Individual
0002: Follower unit of group
0001: Header unit of group 0099: Unfixed
11
Indoor unit capacity 0000: Unfixed 0001 to 0034 According to capacity
type
12 Line address 0001: No.1 unit 0030: No.30 unitto 0099: Unfixed
32 TA sensor selection 0000: Body TA sensor 0001: Remote controller sensor 0000: Body TA sensor
33 Temperature unit select 0000: ûC (at factory shipment) 0001: ûF 0000: ûC
31 Ventilating fan control 0000: Unavailable 0001: Available 0000: Unavailable
13 Indoor unit address 0001: No.1 unit 0064: No.64 unitto 0099: Unfixed
10
Type 0001: 4-way Cassette etc.
* refer to 36 page Type CODE No. [10]
Depending on model
type
0F
Cooling only 0000: Heat pump
0001: Cooling only (No display of [AUTO] [HEAT])
0000: Heat pump
0d
Existence of [AUTO]
mode
0000: Provided
0001: Not provided (Automatic selection from connected outdoor unit)
0001: Not provided
04
Specific indoor unit
priority
0000: No priority 0001: Priority 0000: No priority
03
Central control address 0001: No.1 unit
0099: Unfixed
0064: No.64 unitto 0099: Unfixed
Static pressure selection 0000: Standard
0006
The list abpve is when SW501-1 and SW501-2 is OFF.
120 Pa
Ñ
0005
100 Pa
Ñ
0004
80 Pa
Ñ
0003
50 Pa
AP036
~ 056
(Factory
default)
0002
65 Pa
Ñ
0001
30 Pa
AP007
~ 018
(Factory
default)
0000
40 Pa
AP024
~ 030
(Factory
default)
Set data
External static
pressure
60
Timer setting
(wired remote controller)
0000: Available (can be performed) 0001: Unavailable
(cannot be performed)
0000: Available
92
External interlock
release condition
0000: Operation stopped 0001: Release signal received 0000: Operation
stopped
D0
Whether the power
saving mode can be set
by the remote controller
0000: Invalid 0001: Valid 0001: Valid
5d
