Accessory parts and Parts to be procured locally
H Accessory parts
Refrigerant piping
• Piping material used for the conventional refrigerant cannot be used.
• Use copper pipe only with a wall thickness of 0.8 mm or more for Ø6.4, Ø9.5, Ø12.7.
• Flare nut and flare operations are also different from those of the conventional refrigerant.
Use the flare nut fitted to the indoor unit of the air conditioner.
Shape
This manual
——
M5 × 16L
Part name
Installation Manual
Heat insulating pipe
Installation pattern
Installation gauge
Pattern fixing screw
Heat insulator
Washer
Hose band
Flexible hose
Heat insulator A
Heat insulator B
Q’ty
1
2
1
2
4
1
8
1
1
1
1
Usage
(Ensure handover to customer)
For heat insulation of the pipe connecting section
For checking of ceiling opening and the main unit position
For positioning of the ceiling position
(To be used with the installation pattern)
For attach the installation pattern
For heat insulation of drain connecting section
For hanging unit
For connecting drain pipe
For adjusting core-out of drain pipe
For sealing of wire connecting port
For sealing of wire connecting port
