Toshiba RAS-13SA-E - 11. CAUTIONS ON PC BOARD REPLACEMENT

– 52 –
2. Don't wind the black lead wire around the current trans. (CT. T02)
RY01
C02
RY02
Brown
N L
Power
terminal
block
T02
PC board
Blue
White
Black
1 2
Indoor
terminal
block
ON
OFF
123456
1
2
3
4
5
6
OFF
OFF
ON
OFF
ON
11. CAUTIONS ON REPLACEMENT OF PC BOARD ASSEMBLY
1. Set the switch (SW03) provided on the PC board as follows.
