Toshiba Satellite C55D-A Series User Manual

2. Connect the AC adaptor’s DC output plug to the DC IN 19V jack on
your computer.
Figure 2-3 Connecting the DC output plug to the computer
1
2
1. DC IN 19V jack 2. DC output plug
3. Plug the power cord into a live wall outlet - the DC IN/Battery indicator
should glow.
Opening the display
The display panel can be opened to a wide range of angles for optimal
viewing.
While holding down the palm rest with one hand so that the main body of
the computer is not raised, slowly lift the display panel - this will allow the
angle of the display panel to be adjusted to provide optimum clarity.
Figure 2-4 Opening the display panel
1
1. Display panel
Use reasonable care when opening and closing the display panel. Opening
it vigorously or slamming it shut could damage the computer.
Be careful not to open the display panel too far as this could put stress
on the display panel’s hinges and cause damage.
Do not press or push on the display panel.
Do not lift the computer by the display panel.
Do not close the display panel with pens or any other objects left in
between the display panel and the keyboard.
User's Manual 2-5

Toshiba Satellite C55D-A Series Specifications

General

Storage	500GB HDD (5400 RPM)
Graphics	AMD Radeon HD 8330
Optical Drive	DVD-SuperMulti drive (+/-R double layer)
Wireless	Wi-Fi 802.11b/g/n
Screen Resolution	1366 x 768
USB Ports	1x USB 3.0, 2x USB 2.0
HDMI	Yes
Webcam	HD webcam with microphone
Processor	AMD A4-5000
RAM	4GB DDR3L 1600MHz
Display	15.6" HD TruBrite LED Backlit Display
Operating System	Windows 8
Battery	4-Cell Lithium Ion
Bluetooth	Bluetooth 4.0
Ports	1 x USB 3.0, 2 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x RJ-45, 1 x Headphone/Microphone combo port
LAN	10/100 Ethernet
