Toshiba Satellite C55D-A Series User Manual

2. Grasp the disc tray gently and pull until it is fully opened.
Figure 4-2 Pressing the eject button and pulling the disc tray open
2
1
1. Eject button 2. Disc tray
3. Lay the disc, label side up, in the disc tray.
Figure 4-3 Inserting a disc
1
1. Laser lens
When the disc tray is fully opened, the edge of the computer will cover the
disc tray slightly. Therefore, you will need to turn the disc at an angle when
you place it in the disc tray. After seating the disc, however, make sure it
lies flat.
Do not touch the laser lens or any portion of its surrounding casing as
this could cause misalignment.
Prevent foreign objects from entering the drive. Check the surface of
the disc tray, especially the area behind the front edge of the disc tray,
to make sure there are no such objects before closing the drive.
4. Press gently at the center of the disc until you feel it click into place.
The disc should lie below the top of the spindle, flush with the spindle
base.
5. Push the center of the disc tray to close it. Press gently until it locks
into place.
If the disc is not seated properly when the disc tray is closed, the disc might
be damaged. Also, the disc tray might not open fully when you press the
eject button.
User's Manual 4-7

Toshiba Satellite C55D-A Series Specifications

General

Storage	500GB HDD (5400 RPM)
Graphics	AMD Radeon HD 8330
Optical Drive	DVD-SuperMulti drive (+/-R double layer)
Wireless	Wi-Fi 802.11b/g/n
Screen Resolution	1366 x 768
USB Ports	1x USB 3.0, 2x USB 2.0
HDMI	Yes
Webcam	HD webcam with microphone
Processor	AMD A4-5000
RAM	4GB DDR3L 1600MHz
Display	15.6" HD TruBrite LED Backlit Display
Operating System	Windows 8
Battery	4-Cell Lithium Ion
Bluetooth	Bluetooth 4.0
Ports	1 x USB 3.0, 2 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x RJ-45, 1 x Headphone/Microphone combo port
LAN	10/100 Ethernet
