Toshiba Satellite C55D-A Series User Manual

Figure 3-3 The right side of the computer
87
1
3
2
4 5 6
1. Headphone jack 5. HDMI out port*
2. Microphone jack 6. LAN jack*
3. Universal Serial Bus (USB 2.0 or 3.0)
port*
7. External RGB monitor port*
4. Universal Serial Bus (USB 2.0) port 8. Cooling vents
* Provided with some models.
Product appearance depends on the model you purchased.
Headphone jack A 3.5 mm mini headphone jack enables
connection of stereo headphones.
Microphone jack A 3.5 mm mini microphone jack enables
connection of a mini jack for monaural
microphone input.
The integrated sound system provides support for the computer's internal
speakers and microphone, as well as allowing an external microphone and
headphones to be connected via the appropriate jacks.
Universal Serial Bus
(USB 2.0 or 3.0) port
One Universal Serial Bus port, which complies to
the USB 2.0 or 3.0 standard, is provided on the
right side of the computer.
The USB port type may vary depending on the
model you purchased. The port with blue color is
USB 3.0 port.
The USB 2.0 port is compliant with USB 2.0
standard and not compatible with USB 3.0
devices.
The USB 3.0 port is compliant with USB 3.0
standard and backward compatible with USB 2.0
devices.
USB 3.0 port(s) may work as USB 2.0 port(s) when operating in USB
Legacy Emulation mode.
User's Manual 3-4

Toshiba Satellite C55D-A Series Specifications

General

Storage	500GB HDD (5400 RPM)
Graphics	AMD Radeon HD 8330
Optical Drive	DVD-SuperMulti drive (+/-R double layer)
Wireless	Wi-Fi 802.11b/g/n
Screen Resolution	1366 x 768
USB Ports	1x USB 3.0, 2x USB 2.0
HDMI	Yes
Webcam	HD webcam with microphone
Processor	AMD A4-5000
RAM	4GB DDR3L 1600MHz
Display	15.6" HD TruBrite LED Backlit Display
Operating System	Windows 8
Battery	4-Cell Lithium Ion
Bluetooth	Bluetooth 4.0
Ports	1 x USB 3.0, 2 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x RJ-45, 1 x Headphone/Microphone combo port
LAN	10/100 Ethernet
