Universal Serial Bus
(USB 2.0) port
One Universal Serial Bus port, which complies to
the USB 2.0 standard, is provided on the right
side of the computer.
The USB 2.0 port is not compatible with USB 3.0
devices.
LAN jack This jack lets you connect to a LAN. The adaptor
has built-in support for Ethernet LAN (10
megabits per second, 10BASE-T), or Fast
Ethernet LAN (100 megabits per second,
100BASE-TX). Refer to Operating Basics, for
details.
Do not connect any cable other than a LAN cable to the LAN jack. It could
cause damage or malfunction.
Security lock slot A security cable can be attached to this slot and
then connected to a desk or other large object in
order to deter theft of the computer.
Back (CL10-C/L10-C)
The following figure shows the back of the computer.
Figure 3-4 The back of the computer (CL10-C/L10-C)
Underside (CL10-C/L10-C)
The following figures show the underside of the computer. Ensure that the
display is closed before the computer is turned over to avoid causing any
damage.
User's Manual
3-5
