Figure 3-5 The underside of the computer (CL10-C/L10-C)
1. Stereo speakers 2. Force Shut down hole
Product appearance depends on the model you purchased.
Stereo speakers The speakers emit sound generated by your
software as well as audio alarms, such as low
battery condition, generated by the system.
Force Shut down hole Insert a slender object such as a needle into this
hole to force a shut down when the computer is
hung.
Front with the display open (CL10-C/L10-C)
This section shows the computer with the display panel open. In order to
open the display, lift up the display panel and position it at a comfortable
viewing angle for you.
Figure 3-6 The front of the computer with the display panel open (CL10-C/L10-C)
User's Manual
3-6
