Toshiba Satellite P200 User Manual

4 Replacement Procedures 4.13 Wireless LAN Unit
4.13 Wireless LAN Unit
Removing the Wireless LAN Unit
To remove wireless LAN unit, first remove the keyboard and the wireless LAN antennas as
described in the previous section. Then follow the steps below:
1. Remove the two M2x2.5 screws securing the wireless LAN module. The LAN unit will
pop up.
Figure 4-38 Removing the wireless LAN unit screws
2. Grasp the wireless LAN unit and pull it out.
Figure 4-39 Removing the wireless LAN card
CAUTION: Do not touch the connectors on the wireless LAN unit or on the
computer. Debris on the connectors may cause malfunction.
4-36 [CONFIDENTIAL] Satellite P200 / P205 Series Maintenance Manual

Toshiba Satellite P200 Specifications

General

Processor	Intel Core 2 Duo
Display	17-inch
Display Resolution	1440x900 pixels
RAM	Up to 4GB
Graphics	Intel GMA X3100
Operating System	Windows Vista
Chipset	Intel
Optical Drive	DVD SuperMulti drive
Wireless	Wi-Fi 802.11a/b/g
