Toshiba TC Series User Manual

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
42
3B)
3C)
• To insert termination resistance of 100Ω on the External Device, short-circuit jumper JP2.
• For the External Device connector, use the XH connector (XHP-7) by J.S.T. Mfg.
• To insert termination resistance of 100Ω on the External Device, short-circuit jumper JP2.
• For the External Device connector, use the XH connector (XHP-7) by J.S.T. Mfg.
Signal name
Signal name
Pin
3
4
7
RDA
RDB
SDA
SDB
SG
ERA
CSA
ERB
CSB
FG
RXD+
RXD-
FG
User-created cable
Display side
D-sub 9pin (socket)
Display
External Device side
Pin
1
2
3
7
5
4
8
9
6
Shell
Terminal
resistance
100Ω
Shield
Signal name
TRM
RDA
RDB
SDA
SDB
SG
FG
User-created cable
Display side
Terminal block
CA4-ADPONL-01
CA3-ADPTRM-01
Display
Signal name
Pin
3
4
7
RXD+
RXD-
FG
External Device side
Shield
