Toshiba TC Series User Manual

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
41
3A)
*3 All GP3000 models except the GP-3200 Series and AGP-3302B
*4 Only COM ports that support RS-422/485 (2 wire) communication.
)" IPC COM Port" (page 5)
*5 Except GP-4203T
*6 All GP4000 models except GP-4100 Series, GP-4*01TM, GP-4201T and GP-4*03T
*7 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block
Conversion Adapter, refer to Cable Diagram 3A.
• To insert termination resistance of 100Ω on the External Device, short-circuit jumper JP2.
• For the External Device connector, use the XH connector (XHP-7) by J.S.T. Mfg.
Signal name
TRM
RDA
RDB
SDA
SDB
SG
FG
User-created cable
Display side
Terminal block
Signal name
Pin
3
4
7
RXD+
RXD-
FG
External Device side
CA3-ADPCOM-01
CA3-ADPTRM-01
Display
Shield

Toshiba TC Series Specifications

General

Brand	Toshiba
Model	TC Series
Category	Control Unit
Language	English
