Toshiba TC Series - Device Code and Address Code; TC200 series

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
79
7 Device Code and Address Code
Use device code and address code when you select "Device Type & Address" for the address type in data displays.
7.1 TC200 series
Device Device Name
Device Code
(HEX)
Address Code
*1
*1 Please refer to the *1 in "6 Supported Devices" for the Rack No. and the Position.
Input Relay 1 X 0080 Rack No. × 0x08 + Position
Output Relay 1 Y 0082 Rack No. × 0x08 + Position
Internal Relay R 0084 Rack No. × 0x08 + Position
Extended Internal Relay 1 G 0085 Rack No. × 0x08 + Position
Extended Internal Relay 2 H 0086 Rack No. × 0x08 + Position
Special AUX Relay A 0089 Rack No. × 0x08 + Position
Latch Relay L 008A Rack No. × 0x08 + Position
Shift Register S 008B Rack No. × 0x08 + Position
Edge Relay E 008C Rack No. × 0x08 + Position
Timer (contact) T 008D Rack No. × 0x08 + Position
Counter (contact) C 008E Rack No. × 0x08 + Position
Timer/Counter (current value) P 0002 Rack No. × 0x08 + Position
Timer/Counter (setup value) V 0003 Rack No. × 0x08 + Position
Generic Register 1 D 0000 Rack No. × 0x08 + Position
Generic Register 2 B 0001 Rack No. × 0x08 + Position
