TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
80
7.2 TC200S series
Device Device Name
Device Code
(HEX)
Address Code
*1
*1 Please refer to the *1 in "6 Supported Devices" for the Rack No. and the Position.
Input Relay 1 X 0080 Rack No. × 0x08 + Position
Input Relay 2 I 0081 Rack No. × 0x08 + Position
Output Relay 1 Y 0082 Rack No. × 0x08 + Position
Output Relay 2 O 0083 Rack No. × 0x08 + Position
Internal Relay R 0084 Rack No. × 0x08 + Position
Extended Internal Relay 1 G 0085 Rack No. × 0x08 + Position
Extended Internal Relay 2 H 0086 Rack No. × 0x08 + Position
Extended Internal Relay 3 J 0087 Rack No. × 0x08 + Position
Extended Internal Relay 4 K 0088 Rack No. × 0x08 + Position
Special AUX Relay A 0089 Rack No. × 0x08 + Position
Latch Relay L 008A Rack No. × 0x08 + Position
Shift Register S 008B Rack No. × 0x08 + Position
Edge Relay E 008C Rack No. × 0x08 + Position
Timer (contact) T 008D Rack No. × 0x08 + Position
Counter (contact) C 008E Rack No. × 0x08 + Position
Timer/Counter (current value) P 0002 Rack No. × 0x08 + Position
Timer/Counter (setup value) V 0003 Rack No. × 0x08 + Position
Generic Register 1 D 0000 Rack No. × 0x08 + Position
Generic Register 2 B 0001 Rack No. × 0x08 + Position
Generic Register 3 U 0004 Rack No. × 0x08 + Position
Generic Register 4 M 0005 Rack No. × 0x08 + Position
Generic Register 5 Q 0006 Rack No. × 0x08 + Position
To Next Page
