Toshiba TC Series User Manual

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
81
7.3 TCmini series
 TC9-00
 TC8-00/TC5-02
Device Device Name
Device Code
(HEX)
Address Code
*1
*1 Please refer to the *1 in "6 Supported Devices" for the Rack No. and Position.
Input Relay 1 X 0080 Rack No. × 0x08 + Position
Output Relay 1 Y 0082 Rack No. × 0x08 + Position
Internal Relay
X 0080 Rack No. × 0x08 + Position
Y 0082 Rack No. × 0x08 + Position
R 0084 Rack No. × 0x08 + Position
Special AUX Relay A 0089 Rack No. × 0x08 + Position
Latch Relay L 008A Rack No. × 0x08 + Position
Edge Relay E 008C Rack No. × 0x08 + Position
Timer (contact) T 008D Rack No. × 0x08 + Position
Counter (contact) C 008E Rack No. × 0x08 + Position
T/C Register 1 P 0002 Rack No. × 0x08 + Position
T/C Register 2 V 0003 Rack No. × 0x08 + Position
Data Register D 0000 Rack No. × 0x08 + Position
Device Device Name
Device Code
(HEX)
Address Code
*1
*1 Please refer to the *1 in "6 Supported Devices" for the Rack No. and the Position.
Input Relay 1 X 0080 Rack No. × 0x08 + Position
Output Relay 1 Y 0082 Rack No. × 0x08 + Position
Internal Relay R 0084 Rack No. × 0x08 + Position
Special AUX Relay A 0089 Rack No. × 0x08 + Position
Latch Relay L 008A Rack No. × 0x08 + Position
Edge Relay E 008C Rack No. × 0x08 + Position
Timer (contact) T 008D Rack No. × 0x08 + Position
Counter (contact) C 008E Rack No. × 0x08 + Position
T/C Register 1 P 0002 Rack No. × 0x08 + Position
T/C Register 2 V 0003 Rack No. × 0x08 + Position
Data Register D 0000 Rack No. × 0x08 + Position
