Toshiba TC Series User Manual

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
46
3H)
3I)
• The 5V output (Pin #6) on the Display is the power supply for Siemens AG's
PROFIBUS connector. Do not use it for other devices.
• In the GP-4107 COM port, the SG and FG terminals are isolated.
• To insert termination resistance of 100Ω on the External Device, short-circuit jumper JP2.
• For the External Device connector, use the XH connector (XHP-7) by J.S.T. Mfg.
• To insert termination resistance of 100Ω on the External Device, short-circuit jumper JP2.
• For the External Device connector, use the XH connector (XHP-7) by J.S.T. Mfg.
Signal name
Signal name
Pin
3
4
7
LINE(+)
LINE(-)
NC
NC
GND(SG)
RS(RTS)
5V
NC
NC
FG
RXD+
RXD-
FG
User-created cable
Display side
D-sub 9pin (plug)
Display
External Device side
Pin
3
8
1
2
5
4
6
7
9
Shell
Terminal
resistance
100Ω
Shield
Signal name
TRM
RDA
RDB
SDA
SDB
SG
FG
User-created cable
Display side
Terminal block
Signal name
Pin
3
4
7
RXD+
RXD-
FG
External Device side
PFXZCBADTM1
Display
Shield
