TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
52
4F)
• To insert termination resistance of 120Ω on the External Device, turn on DIP Switch SW2-7.
• For the External Device connector, use the XH connector (XHP-6) by J.S.T. Mfg.
Signal name
Signal name
Pin
1
2
6
DATA+
DATA-
NC
NC
GND(SG)
ERA
CSA
ERB
CSB
FG
A
B
FG
User-created cable
Display side
D-sub 9pin (socket)
Display
External Device side
Pin
1
2
3
7
5
4
8
9
6
Shell
Terminal
resistance
120Ω
Shield
