Toshiba TC Series User Manual

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
66
6B)
6C)
• Termination resistance of 120Ω is built into the External Device.
• For the External Device connector, use the XA connector (XAP-03V-1) by J.S.T. Mfg.
• Termination resistance of 120Ω is built into the External Device.
• For the External Device connector, use the XA connector (XAP-03V-1) by J.S.T. Mfg.
Signal name
Signal name
Pin
1
2
3
RDA
RDB
SDA
SDB
SG
ERA
CSA
ERB
CSB
FG
A
B
SG
User-created cable
Display side
D-sub 9pin (socket)
Display
External Device side
Pin
1
2
3
7
5
4
8
9
6
Shell
Terminal
resistance
120Ω
Shield
Signal name
TRM
RDA
RDB
SDA
SDB
SG
FG
User-created cable
Display side
Terminal block
CA4-ADPONL-01
CA3-ADPTRM-01
Display
Signal name
Pin
1
2
3
A
B
SG
External Device side
Shield
