Toshiba TC Series User Manual

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
67
6D)
6E)
• Termination resistance of 120Ω is built into the External Device.
• For the External Device connector, use the XA connector (XAP-03V-1) by J.S.T. Mfg.
• Termination resistance of 120Ω is built into the External Device.
• For the External Device connector, use the XA connector (XAP-03V-1) by J.S.T. Mfg.
Signal name
Signal name
Pin
1
2
3
TERMRX
RDA
RDB
SDA
SDB
SG
FG
A
B
SG
User-created cable
Display side
D-sub 9pin (plug)
Display
External Device side
Pin
1
2
7
3
8
5
Shell
CA4-ADPONL-01
Shield
Display
CA3-ADPCOM-01
CA3-ADPTRM-01
User-created cable
Signal name
Signal name
Pin
1
2
3
A
B
SG
Display side
Terminal block
External Device side
TRM
RDA
RDB
SDA
SDB
SG
FG
Shield
