TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
68
6F)
• Termination resistance of 120Ω is built into the External Device.
• For the External Device connector, use the XA connector (XAP-03V-1) by J.S.T. Mfg.
Signal name
Signal name
Pin
1
2
3
DATA+
DATA-
NC
NC
GND(SG)
ERA
CSA
ERB
CSB
FG
A
B
SG
User-created cable
Display side
D-sub 9pin (socket)
Display
External Device side
Pin
1
2
3
7
5
4
8
9
6
Shell
Terminal
resistance
120Ω
Shield
