Appendix B: Pin out description of VGA and RS232 sockets
Before connecting any external equipment, turn off all main power switches. If there is no switch, remove
the mains plug from the wall socket. Signal information for Mini VGA 15 pin connector
VGA Pinout
Pin Name
1 RED
2 GREEN
3 BLUE
4 RES
5 GND
6 RGND
7 GGND
8 BGND
9 +5V
10 SGND
11 ID0
12 SDA
13 HSYNC or CSYNC
14 VSYNC
15 SCL
RS232 Pinout
DE-9 Pin Signal Name
1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
