Toshiba TDP-T8 - Disassemble Lamp, Keypad Board, Top Cover and

2-2
S8 T8 T9
No Procedure Photo
1 Loosen 2 screws to remove
the Lamp Cover
2 Loosen 2 screws to remove
Lamp Module
3
Unscrew 1 screw and press
the left tenon (A) on the
lower cover first and then
press the right one (B) on
the lower cover to pull the
bilateral sides to remove
Top Cover.
2-2 Disassemble Lamp, Keypad Board, Top Cover and Front
Cover
Lamp Cover
Lamp
A B
Pull
Top Cover
