No Procedure Photo
3
Unplug 2 connectors to
remove 2 pin connector
and 14 pin connector from
LVPS.
4
Unscrew 1 screw to remove
Thermal Sensor Board.
5
Unscrew 2 screws to re-
move Fan Module.
Thermal Sensor Board
Fan Module
