Toshiba TECRA A50-C User Manual

Figure 2-1 Connecting the power cord to the AC adaptor (2-pin plug)
Figure 2-2 Connecting the power cord to the AC adaptor (3-pin plug)
Either a 2-pin or 3-pin adaptor/cord is included with the computer
depending on the model.
2. Connect the DC output plug of the AC adaptor to the DC IN 19V jack
on your computer.
Figure 2-3 Connecting the DC output plug to the computer
1
2
1. DC IN 19V jack 2. DC output plug
Product appearance depends on the model you purchased.
3. Plug the power cord into a live wall outlet. The DC IN/Battery indicator
glows.
Opening the display
The display panel can be opened to a wide range of angles for optimal
viewing.
While holding down the palm rest with one hand so that the main body of
the computer is not raised, slowly lift the display panel. This will allow the
angle of the display panel to be adjusted to provide optimum clarity.
User's Manual
2-4

Toshiba TECRA A50-C Specifications

General

Graphics	Intel HD Graphics 520
Operating System	Windows 10 Pro
Wireless	Wi-Fi 802.11ac, Bluetooth 4.0
Processor	Intel Core i5-6200U
RAM	4GB DDR3L
Storage	500GB HDD
Display	15.6-inch, 1366x768 or 1920x1080
Battery Life	Up to 8 hours
Battery	4-cell, 45Wh
Ports	USB 3.0, USB 2.0, HDMI, VGA, Ethernet, SD card reader, headphone/mic combo
