12 ASC25 Instruction Manual
(2) Functional specifications
The functional specifications of the Active Star Coupler are listed below.
Item Description
Number of connectable
stations
Max. 10
for FC Type
connector
Silica glass optical fiber cable (JIS C6820)
GI 50/125 µm (core dia./clad dia.)
Applied optical fiber
for F07 Type
connector
H-PCF (hard clad silica glass core fiber) cable
SI Model 200/230µm (core dia./clad dia.)
Transmission distance
Station to Star Coupler : Max. 1 km
Star Coupler to Star Coupler : Max. 1 km
Total system : Max. 10 km
Number of daisy-chain
connection of Star
Couplers
Max. 9
Connectable apparatus TOSLINE-S20 fiber optic network stations.
HEALTHY contact (Relay
contact)
"ON" during normal operation
Contact rating
Voltage: 250 V AC Current: max. 1 A
Voltage: 24 V DC Current: max. 1 A
Voltage: 5 V AC/DC Current: min. 10 mA
Table 5.2
