TOSLINE-S20 Active Star Coupler (ASC25) Instruction Manual 6F3B0360
TOSLINE S20 11
5. Specifications
The section describes the specifications of the Active Star Coupler.
(1) General specifications
General specifications of Active Star Coupler are given below.
Item Specification
Rating 100/110 V AC, 50/60 Hz
200/220 V AC, 50/60 Hz
Voltage
Fluctuation range 85 to 132 V AC, 47 to 66 Hz
170 to 250 V AC, 47 to 66 Hz
Power consumption about 10 VA
Retentive power interruption Resuming to normal operation within 10 ms
Insulation rating 1500 V AC for 1 minute
Power
Supply
Fuse rating 250V-3A
Operating
temperature
0 to +55°C (unit ambient temperature)Tempe-
rature
Storage
temperature
−20 to +75°C (unit ambient temperature)
Humidity 20 to 90% RH, no condensation
Vibration Conforming to JIS C0911
• Power OFF, Frequency 16.7 Hz, Displacement 3 mm
Atmosphere Free from corrosive gas
Dust Not more than 1 mg/m
3
Environ-
ment
Ground Grounding resistance 100Ω or less
External dimensions 390 (W) × 200 (D) × 70 (H) mm
Weight approximately 3.0 kg
Cooling Natural air cooling
Installation position
Horizontal (unacceptable of upside down or vertical
position)
Table 5.1
