10
E6582188
Step 6B
Connect Part (D) between Part (C) and Inverter by the attached Nuts M8 (3pcs) and M8 nuts which are removed at Step 3.
Tightening torque of M8 nuts: 11.8Nm
Go to Step7
These 3pcs nuts (removed at Step 3) must be reused.
The attached
Nuts (M8)
(D)
