15
4. Attach the rain shield and rain shield support to the outside of the window panel
by using the included nut, spring washer, washer, and bolts.
nut
spring washer
washer
bolt
support
nut
spring washer
screws
washer
rain shield
5. Cut Sponge B to the width of your window and attach it to the bottom of the
window sill.
sponge B (adhesive)
6. Place the assembled window panel on the window sill and adjust until it fully
covers the width of your window, then screw the window panel into place on
the window sill.
Adjustment panel
Window panel assemble
adjustment panel
Screws
20.5"~37.4"
To Next Page
