34
Outdoor Unit Installation
minimum 19.7in (50 cm)
minimum 78.7in (200 cm)
1. Select a Installation Site
Refer to the following diagram to ensure proper space around the unit:
minimum 19.7in (50 cm)
minimum 11.8 in (30 cm)
Appropriate install locations should follow these standards:
● Open ventilation space around the air conditioner to ensure airflow.
● Location must be convenient to install and not disturb others.
● Protected from prolonged periods of direct sunlight exposure.
● Strong enough to support the weight of the unit.
DO NOT install the unit in the following locations:
● Near an obstacle that will block air inlets and outlets.
● Near a public street, crowded areas, or where noise from the unit will disturb
others.
● Near animals or plants that will be harmed by hot air discharge.
● Near any source of combustible gas or area that is exposed to large amounts
of dust.
● Near excessive amounts of salty air.
minimum
11.8 in (30 cm)
