Technical Information
Service Manual
Model TW09HQ2C2D
Product Code CB439005801_X18545
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 9000(3100~9600)
Heating Capacity(Min~Max) Btu/h 11000(1911~12000)
Cooling Power Input(Min~Max) W 630(160~1300)
Heating Power Input(Min~Max) W 1020(160~1350)
Cooling Power Current A 2.80
Heating Power Current A 3.50
Rated Input W 1350
Rated Current A 6.0
Air Flow Volume(SH/H/M/L) CFM 377/288/241/171
Dehumidifying Volume Pint/h 1.69
EER (Btu/h)/W 14.29
COP (Btu/h)/W 10.78
SEER 23.00
HSPF 10.50
Application Area yd
2
14.35-21.53
Indoor Unit
Model of indoor unit TW09HQ2C2DI
Indoor Unit Product Code CB439N05801_X18545
Fan Type Cross-ow
Diameter Length(DXL) inch Φ3 55/64X25
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1050/750
Fan Motor Heating Speed(SH/H/M/L) r/min 1300/1150/1000/900
Output of Fan Motor W 20
Fan Motor RLA A 0.09
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16
Row-n Gap inch 2-1/18
Coil Length (LXDXW) inch 25X7/8X12 1/16
Swing Motor Model MP24BA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 43/39/35/29
Sound Power Level(SH/H/M/L) dB (A) 53/49/45/39
Dimension (WXHXD) inch 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 36 1/8X11X14 5/16
Dimension of Package (LXWXH) inch 36 1/4X11X15
Net Weight Ib 22.05
Gross Weight Ib 26.46
