Model of Outdoor Unit TW09HQ2C2DO
Outdoor Unit Product Code CB419W04300_X18545
Compressor Manufacturer/Trademark ZHUHAI GREE DAIKIN DEVICE CO.,LTD
Compressor Model 1GDY23AXD
Compressor Oil DAPHNE FVC50K
Compressor Type Swing
Compressor Locked Rotor Amp (L.R.A) A /
Compressor RLA A 6.6
Compressor Power Input W 845
Overload Protector KSD115OC or HPC115/95
Throttling Method Electron expansion valve
Operation temp ºF 61~86
Ambient temp (cooling) ºF 0~115
Ambient temp (heating) ºF -4~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/8
Rows-n Gap inch 2-1/16
Coil Length (LXDXW) inch 29 13/32 X1 3/4X20
Fan Motor Speed rpm 900
Output of Fan Motor W 30
Fan Motor RLA A 0.36
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 1059
Fan Type Axial-ow
Fan Diameter inch Φ15 3/4
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 550
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 240
Sound Pressure Level (H/M/L) dB (A) 53/-/-
Sound Power Level (H/M/L) dB (A) 63/-/-
Dimension (WXHXD) inch 33 13/32X21 1/4X12 19/32
Dimension of Carton Box (LXWXH) inch 34 37/64X14 1/6X22 5/6
Dimension of Package (LXWXH) inch 34 43/64X14 9/32X23 27/64
Net Weight Ib 78.26
Gross Weight Ib 83.78
Refrigerant R410A
Refrigerant Charge oz 45.86
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch Φ1/4
Outer Diameter Gas Pipe inch Φ3/8
Max Distance Height ft 32.8
Max Distance Length ft 49.2
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
