Tosot TW12HQ2C2D User Manual

22
Technical Information
Service Manual
Model TW12HQ2C2D
Product Code CB439005601_X18545
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 12000(3100~13000)
Heating Capacity(Min~Max) Btu/h 13000(2400~14000)
Cooling Power Input(Min~Max) W 960(200~1350)
Heating Power Input(Min~Max) W 1100(400~1400)
Cooling Power Current A 4.50
Heating Power Current A 5.50
Rated Input W 1400
Rated Current A 6.3
Air Flow Volume(SH/H/M/L) CFM 400/288/241/171
Dehumidifying Volume Pint/h 2.96
EER (Btu/h)/W 12.5
COP (Btu/h)/W 11.82
SEER 22.00
HSPF 10.10
Application Area yd
2
19.14-28.70
Indoor Unit
Model of indoor unit TW12HQ2C2DI
Indoor Unit Product Code CB439N05601_X18545
Fan Type Cross-ow
Diameter Length(DXL) inch Φ3 55/64X25
Fan Motor Cooling Speed(SH/H/M/L) r/min 1400/1200/1050/800
Fan Motor Heating Speed(SH/H/M/L) r/min 1400/1200/1000/900
Output of Fan Motor W 20
Fan Motor RLA A 0.09
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16
Row-n Gap inch 2-1/18
Coil Length (LXDXW) inch 25X7/8X12 1/16
Swing Motor Model MP24BA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 45/39/35/29
Sound Power Level(SH/H/M/L) dB (A) 55/49/45/39
Dimension (WXHXD) inch 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 36 1/8X11X14 5/16
Dimension of Package (LXWXH) inch 36 1/4X11X15
Net Weight Ib 22.05
Gross Weight Ib 26.46
