Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit TW12HQ2C2DO
Outdoor Unit Product Code CB419W04500_X18545
Compressor Manufacturer/Trademark ZHUHAI GREE DAIKIN DEVICE CO.,LTD
Compressor Model 1GDY23AXD
Compressor Oil DAPHNE FVC50K
Compressor Type Swing
Compressor Locked Rotor Amp (L.R.A) A /
Compressor RLA A 6.6
Compressor Power Input W 845
Overload Protector KSD115OC or HPC115/95
Throttling Method Electron expansion valve
Operation temp ºF 61~86
Ambient temp (cooling) ºF 0~115
Ambient temp (heating) ºF -4~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/8
Rows-n Gap inch 2-1/16
Coil Length (LXDXW) inch 29 13/32X1 3/4X22
Fan Motor Speed rpm 900
Output of Fan Motor W 30
Fan Motor RLA A 0.36
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 1177
Fan Type Axial-ow
Fan Diameter inch Φ15 3/4
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 550
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 240
Sound Pressure Level (H/M/L) dB (A) 54/-/-
Sound Power Level (H/M/L) dB (A) 64/-/-
Dimension (WXHXD) inch 33 25/64X23 19/64X12 19/32
Dimension of Carton Box (LXWXH) inch 34 37/64X14 1/6X22 5/6
Dimension of Package (LXWXH) inch 34 43/64X14 9/32X23 27/64
Net Weight Ib 85.98
Gross Weight Ib 92.59
Refrigerant R410A
Refrigerant Charge oz 47.62
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch Φ1/4
Outer Diameter Gas Pipe inch Φ1/2
Max Distance Height ft 32.8
Max Distance Length ft 65.6
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
