Technical Information
Service Manual
Model TW18HQ2C2D
Product Code CB439005901_X18545
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 18000(6800~20000)
Heating Capacity(Min~Max) Btu/h 19800(7340~23500)
Cooling Power Input(Min~Max) W 1435(450~2150)
Heating Power Input(Min~Max) W 1730(580~2600)
Cooling Power Current A 6.37
Heating Power Current A 7.68
Rated Input W 3000
Rated Current A 10.39
Air Flow Volume(SH/H/M/L) CFM 559/488/412/335
Dehumidifying Volume Pint/h 1.8
EER (Btu/h)/W 12.50
COP (Btu/h)/W 11.45
SEER 20
HSPF 10
Application Area yd
2
27.51-40.66
Indoor Unit
Model of indoor unit TW18HQ2C2DI
Indoor Unit Product Code CB439N05901_X18545
Fan Type Cross-ow
Diameter Length(DXL) inch Φ4 1/6X27 13/16
Fan Motor Cooling Speed(SH/H/M/L) r/min 1400/1200/1050/800
Fan Motor Heating Speed(SH/H/M/L) r/min 1400/1200/1100/900
Output of Fan Motor W 60
Fan Motor RLA A 0.24
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32
Row-n Gap inch 2-1/18
Coil Length (LXDXW) inch 28 9/64X1X12
Swing Motor Model MP35CJ
Output of Swing Motor W 2.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 47/43/40/39
Sound Power Level(SH/H/M/L) dB (A) 57/53/50/49
Dimension (WXHXD) inch 38 13/64X11 13/16X8 5/6
Dimension of Carton Box (LXWXH) inch 40 55/64X15X12
Dimension of Package (LXWXH) inch 41X15X12 39/64
Net Weight Ib 27.6
Gross Weight Ib 34.2
