25
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit TW18HQ2C2DO
Outdoor Unit Product Code CB419W06700_X18545
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO,LTD.
Compressor Model QXA-B141zF030A
Compressor Oil RB68EP
Compressor Type Rotary
Compressor Locked Rotor Amp (L.R.A) A 25
Compressor RLA A 12.08
Compressor Power Input W 1440
Overload Protector 1NT11L-6233 or KSD115OC or HPC115/95U1
Throttling Method Electron expansion valve
Operation temp ºF 61~86
Ambient temp (cooling) ºF 0~115
Ambient temp (heating) ºF -4~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32
Rows-n Gap inch 3-1/18
Coil Length (LXDXW) inch 36 13/16X1 1/2X25 63/64
Fan Motor Speed rpm 800
Output of Fan Motor W 60
Fan Motor RLA A 0.49
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 3200
Fan Type Axial-ow
Fan Diameter inch Φ20 15/32
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 4.3
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 2.5
Sound Pressure Level (H/M/L) dB (A) 55/-/-
Sound Power Level (H/M/L) dB (A) 65/-/-
Dimension (WXHXD) inch 38X27 9/16X15 19/32
Dimension of Carton Box (LXWXH) inch 40 25/64X17 29/32X28 15/16
Dimension of Package (LXWXH) inch 40 33/64X18 5/16X29 33/64
Net Weight Ib 105.8
Gross Weight Ib 115.8
Refrigerant R410A
Refrigerant Charge oz 56.44
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch Φ1/4
Outer Diameter Gas Pipe inch Φ5/8
Max Distance Height ft 32.8
Max Distance Length ft 82
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
