Technical Information
Service Manual
Model TW24HQ2C2D
Product Code CB439005701_X18545
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 22000(6824~27296)
Heating Capacity(Min~Max) Btu/h 23000(6824~30708)
Cooling Power Input(Min~Max) W 1830(450~3000)
Heating Power Input(Min~Max) W 2000(450~3000)
Cooling Power Current A 8.05
Heating Power Current A 8.35
Rated Input W 3000
Rated Current A 14.49
Air Flow Volume(SH/H/M/L) CFM 706/647/589/530
Dehumidifying Volume Pint/h 4.23
EER (Btu/h)/W 12.02
COP (Btu/h)/W 11.50
SEER 20
HSPF 9
Application Area yd
2
2 32.29-50.23
Indoor Unit
Model of indoor unit TW24HQ2C2DI
Indoor Unit Product Code CB439N05701_X18545
Fan Type Cross-ow
Diameter Length(DXL) inch Φ4 1/4X32 7/10
Fan Motor Cooling Speed(SH/H/M/L) r/min 1300/1100/900/850
Fan Motor Heating Speed(SH/H/M/L) r/min 1300/1100/1000/900
Output of Fan Motor W 60
Fan Motor RLA A 0.38
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 33 1/4X1X13 1/2
Swing Motor Model MP35CJ
Output of Swing Motor W 2.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 48/44/40/36
Sound Power Level(SH/H/M/L) dB (A) 58/54/50/46
Dimension (WXHXD) inch 42 7/16X12 51/64X9 11/16
Dimension of Carton Box (LXWXH) inch 45 5/64X16 9/64X13 3/16
Dimension of Package (LXWXH) inch 45 13/64X16 17/64X13 25/32
Net Weight Ib 34.2
Gross Weight Ib 41.9
