27
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit TW24HQ2C2DO
Outdoor Unit Product Code CB419W03600_X18545
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO,LTD.
Compressor Model QXAS-D23zX090A
Compressor Oil RB68EP
Compressor Type Rotary
Compressor Locked Rotor Amp (L.R.A) A 25
Compressor RLA A 14.67
Compressor Power Input W 2550
Overload Protector 1NT11L-6233/HPC 115/95 /KSD115OC
Throttling Method Electron expansion valve
Operation temp ºF 61~86
Ambient temp (cooling) ºF 0~115
Ambient temp (heating) ºF -4~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32
Rows-n Gap inch 2-1/18
Coil Length (LXDXW) inch 37 31/64X1 1/2X19/32
Fan Motor Speed rpm 820
Output of Fan Motor W 92
Fan Motor RLA A 0.65
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 2354
Fan Type Axial-ow
Fan Diameter inch Φ21 21/32
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 4.3
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 2.5
Sound Pressure Level (H/M/L) dB (A) 59/-/-
Sound Power Level (H/M/L) dB (A) 69/-/-
Dimension (WXHXD) inch 38 37/64X31 7/64X16 13/16
Dimension of Carton Box (LXWXH) inch 42 33/64X19X33
Dimension of Package (LXWXH) inch 42 41/64X19 7/32X33 21/32
Net Weight Ib 142.2
Gross Weight Ib 153.2
Refrigerant R410A
Refrigerant Charge oz 77.6
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.5
Outer Diameter Liquid Pipe inch Φ1/4
Outer Diameter Gas Pipe inch Φ5/8
Max Distance Height ft 32.8
Max Distance Length ft 82
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
